Cold storage room for fruit is widely used to store and keep fruits like banana, strawberry, peach, pear, grape, etc al, in fresh quality. Cold storage room can provide low temperature environment for the fruits by the insulation and cooling system, which can reduce the fruit respiration and the invasion of bacteria. Tropical fruit storage temperature is different from ordinary fruit, tropical fruit storage temperature is generally 10-20 degrees Celsius, the temperature is lower than 8 degrees Celsius, fruit peel easily frozen, resulting in peel black, the temperature is higher than 20 degrees Celsius, the fruit will quickly mature, storage time shorten. All these factors affect the fruits cold room design.

Our Mongolian customer built the fruit cold storage room to keep stored fruits in fresh quality. The design diagram as shown in the following digram.

diagram of Cold Storage Room for fruits in Mongolia
Cold Storage Room for fruits run in Mongolia

OnlyKem Solutions of Fruits Cold Storage Room

  • Cold Room Dimension: 10m*10m*4.5m, 3 sets 3m*3m*3m
  • Usage: Cold Storage Room for Mongolia Fruits Company.
  • Fruit Cold Room Door : 0.8X1.8m hinged door with 0.4×0.4m observation window, do not open the cold room door, we can see the cold room inside the fruit storage situation
  • Fruit Cold Room Inside Temperature: 11~20℃.

Fruits Cold Storage Room Cooling System

We choose the American Copeland brand, ZR series compressor, suitable for high temperature fruits cold room.  And unit cooler are equipped with high quality heating wire.

  1. In the summer, our cooling system will made air cooling to keep the cold room temperature at 11-20 degrees
  2. In the winter , because Mongolian winter ambient temperature of -25 ℃ to -30 ℃, the minimum temperature of -40 ℃. Our unit cooler will made heat to keep the cold room temperature at 11-20 degrees
banana Cold Room in Mongolia

Fruits Cold Room Floor

The 2 layer 50mm thickness XPS and waterproof and 15cm thickness cement.

      1)Good insulation effect.

      2) Good water resistance.

      3) Sufficient load-bearing, can enter a large forklift.

Cold Room for fruits in Mongolia
